基于响应面法优化环孢菌素A发酵工艺的研究

doi:10.19586/j.2095-2341.2025.0006

生物技术进展 ›› 2025, Vol. 15 ›› Issue (3): 518-525.DOI: 10.19586/j.2095-2341.2025.0006

基于响应面法优化环孢菌素A发酵工艺的研究

高晓晶(), 张祝兰(), 林仙菊, 邱观荣, 温耀明, 范建辉, 黄洪祥

福建省微生物研究所，福州 350007

收稿日期:2025-01-20 接受日期:2025-02-28 出版日期:2025-05-25 发布日期:2025-07-01
通讯作者: 张祝兰
作者简介:高晓晶 E-mail: tju_gaoxiaojing@163.com；
基金资助:
福建省公益类科研院所专项(2023R1005002)

Optimization of Fermentation Culture Conditions for Cyclosporine A Using Response Surface Method

Xiaojing GAO(), Zhulan ZHANG(), Xianju LIN, Guanrong QIU, Yaoming WEN, Jianhui FAN, Hongxiang HUANG

Fujian Provincial Key Laboratory of Screening for Novel Microbial Products，Fujian Institute of Microbiology，Fuzhou 350007，China

Received:2025-01-20 Accepted:2025-02-28 Online:2025-05-25 Published:2025-07-01
Contact: Zhulan ZHANG

摘要/Abstract

摘要：

环孢菌素A（cyclosporin A，CsA）作为一种兼具免疫抑制、抗菌、抗炎等多种生物活性的次级代谢产物，在临床治疗和生物医药领域具有重要的应用价值。为了进一步提升CsA的发酵含量，以单因素试验为基础，采用Plackett-Burman设计、中心组合（central composite，CCD）设计及响应面分析法（response surface analysis，RSM）获取最优发酵条件。结果表明，玉米浆粉、硫酸铵、葡萄糖的含量及发酵时间对CsA的生物合成具有显著影响，最终确定适配的培养基组成为8.0%麦芽糊精、6.88%玉米浆粉、0.15%酵母浸粉、0.18%硫酸铵、0.61%葡萄糖和0.1% PEG200，最适的发酵温度和时间为24 ℃，和10.8 d。经发酵工艺优化后，CsA的发酵含量达11.76 mg·mL^-1，较初始条件提高了47.95%。研究结果可为该菌株的工艺放大提供重要的理论依据和技术参数。

关键词: 环孢菌素A, 发酵工程, 响应面法

Abstract:

Cyclosporin A （CsA） is a secondary metabolite with multiple biological activities such as immunosuppression， antibacterial， and anti-inflammatory effects， which holds significant application value in clinical treatment and the biomedical field. To further increase the fermentation content of CsA， based on single-factor experiments， the optimal fermentation conditions were obtained through Plackett-Burman design， central composite design （CCD） and response surface analysis （RSM）. The results indicated that the contents of corn steep powder， ammonium sulfate， glucose， and the fermentation time had a significant impact on the biosynthesis of CsA. Eventually， the suitable medium composition was determined as follows： 8.0% maltodextrin， 6.88% corn steep powder， 0.15% yeast extract powder， 0.18% ammonium sulfate， 0.61% glucose， and 0.1% PEG200. The optimized fermentation parameters were a cultivation temperature of 24 ℃ and a fermentation time of 10.8 days. The fermentation yield of CsA reached 11.76 mg·mL^-1， which was increased by 47.95% compared with the initial conditions， after the optimization of the fermentation process. The research results provide important theoretical basis and technical parameters for the process scale-up of this strain.

Key words: cyclosporin A, fermentation engineering, response surface methodology

中图分类号:

Q939.92

高晓晶, 张祝兰, 林仙菊, 邱观荣, 温耀明, 范建辉, 黄洪祥. 基于响应面法优化环孢菌素A发酵工艺的研究[J]. 生物技术进展, 2025, 15(3): 518-525.

Xiaojing GAO, Zhulan ZHANG, Xianju LIN, Guanrong QIU, Yaoming WEN, Jianhui FAN, Hongxiang HUANG. Optimization of Fermentation Culture Conditions for Cyclosporine A Using Response Surface Method[J]. Current Biotechnology, 2025, 15(3): 518-525.

图/表 11

参考文献 23

1	PATOCKA J, NEPOVIMOVA E, KUCA K, et al.. Cyclosporine A: chemistry and toxicity-a review[J]. Curr. Med. Chem., 2021, 28(20): 3925-3934.
2	郑孝贤. 多孔木霉菌的菌丝形态分化与环孢菌素A合成关系的初步研究[J]. 生物技术进展, 2013, 3(2): 140-144.
	ZHENG X X. The relationship between morphological differentiation and cyclosporin a synthesis in Tolypocladium niveum [J]. Curr. Biotechnol., 2013, 3(2): 140-144.
3	CUI W, CHEN S, HU T, et al.. Nanoceria-mediated cyclosporin a delivery for dry eye disease management through modulating immune-epithelial crosstalk[J]. ACS Nano, 2024, 18(17): 11084-11102.
4	HATAYA Y, NOMURA T, FUJISHIMA Y, et al.. Development of chronic thyroiditis during cyclosporin a treatment[J/OL]. JCEM Case Rep., 2024, 2(12): luae211[2025-04-22]. .
5	BABU P, PATEL Y, PANY S, et al.. Study of physiological parameters and rheology for the production and extraction of cyclosporin A[J]. Int. J. Res. Appl. Sci. Eng. Technol., 2022, 10(4): 394-399.
6	PANDEY S, TRIPATHI P, GUPTA A, et al.. A comprehensive review on possibilities of treating psoriasis using dermal cyclosporine[J]. Drug Deliv. Transl. Res., 2022, 12(7): 1541-1555.
7	SURVASE S A, KAGLIWAL L D, ANNAPURE U S, et al.. Cyclosporin A: a review on fermentative production, downstream processing and pharmacological applications[J]. Biotechnol. Adv., 2011, 29(4): 418-435.
8	姜俊云, 董惠钧, 闫同顺. 雪白白僵菌产环孢菌素A分批补料发酵动力学[J]. 食品与发酵工业, 2012, 38(4): 53-56.
	JIANG J Y, DONG H J, YAN T S. Fed-batch fermentation kinetics of cyclosporine a by Beauveria nivea [J]. Food Ferment. Ind., 2012, 38(4): 53-56.
9	戴梦, 刘静, 赵颖, 等. 环孢菌素A生产菌原生质体转化系统的建立[J]. 化学与生物工程, 2013, 30(3): 36-38.
	DAI M, LIU J, ZHAO Y, et al.. Construction of protoplasts transformation system for cyclosporin a industrial strain[J]. Chem. Bioeng., 2013, 30(3): 36-38.
10	彭婷, 江丹, 陈阳, 等. 响应面法优化桑叶提取液脱色工艺及其对α-葡萄糖苷酶抑制活性[J]. 食品与发酵科技, 2024, 60(6):62-69.
	PENG T, JIANG D, CHEN Y, et al.. Optimization of decolorization process of mulberry leaf extract using response surface methodology and its inhibitory activity on α‍-glucosidase[J]. Food Ferment. Sci. Technol., 2024, 60(6): 62-69.
11	张春丹, 乔洁, 解春艳, 等. 响应面法优化山楂皮渣总黄酮提取工艺及抗氧化活性研究[J]. 廊坊师范学院学报(自然科学版), 2024, 24(4): 49-55.
	ZHANG C D, QIAO J, XIE C Y, et al.. Optimization ethanol extraction of total flavonoids from hawthorn pomace by response surface methodology and antioxidant activity[J]. J. Langfang Norm. Univ. Nat. Sci. Ed., 2024, 24(4): 49-55.
12	徐广新, 杨仁琴, 周炜, 等. 响应面法优化桂花酒酿酸奶制备工艺[J]. 食品安全质量检测学报, 2024, 15(23): 145-151.
	XU G X, YANG R Q, ZHOU W, et al.. Optimization of preparation process of Osmanthus yoghurt with fermented glutinous rice by response surface methodology[J]. J. Food Saf. Qual., 2024, 15(23): 145-151.
13	梁子昌, 陈明, 李大宁, 等. 响应面法优化牛大力茎总黄酮提取工艺[J]. 化学与生物工程, 2024, 41(12): 30-35.
	LIANG Z C, CHEN M, LI D N, et al.. Optimization in extraction process of total flavonoids from Millettia speciosa Champ.stem by response surface methodology[J]. Chem. Bioeng., 2024, 41(12): 30-35.
14	王喜龙, 张丽蓉, 欧晓彬, 等. 响应面法优化紫苏叶中抑菌成分的提取工艺[J]. 化学与生物工程, 2024, 41(12): 36-43.
	WANG X L, ZHANG L R, OU X B, et al.. Optimization in extraction process of bacteriostatic components from Perilla leaves by response surface methodology[J]. Chem. Bioeng., 2024, 41(12): 36-43.
15	林仙菊, 张祝兰, 严凌斌, 等. ARTP诱变选育环孢菌素A高产菌株及发酵工艺优化[J]. 工业微生物, 2023, 53(4): 158-163.
	LIN X J, ZHANG Z L, YAN L B, et al.. Study on screening of high-yield cyclosporin a producing strain by atmospheric and room temperature plasma mutagenesis and optimization of fermentation conditions[J]. Ind. Microbiol., 2023, 53(4): 158-163.
16	严凌斌, 张祝兰, 张引, 等. 响应面法优化他克莫司发酵培养基中无机盐组合[J]. 中国抗生素杂志, 2020, 45(10): 994-999.
	YAN L B, ZHANG Z L, ZHANG Y, et al.. Optimization of inorganic salts of fermentation medium for tacrolimus production by response surface methodology[J]. Chin. J. Antibiot., 2020, 45(10): 994-999.
17	祃栋猛, 陆信曜, 陈文强, 等. 发酵后期补加2种氮源对克雷伯氏菌合成1,3-丙二醇的影响[J]. 食品与发酵工业, 2016, 42(8): 8-12.
	MA D M, LU X Y, CHEN W Q, et al.. Influences on the biosynthesis of 1, 3-propanediol in Klebsiella pneumonia by feeding two types of nitrogen source at the late stage of fermentation[J]. Food Ferment. Ind., 2016, 42(8): 8-12.
18	卫云路, 郑成, 宁正祥. 表面活性剂作为发酵促进剂的国内外研究进展[J]. 化工进展, 2008, 27(7): 983-989.
	WEI Y L, ZHENG C, NING Z X. Research progress of surfactants as fermentation accelerator[J]. Chem. Ind. Eng. Prog., 2008, 27(7): 983-989.
19	周丽, 石彦鹏, 牛春, 等. 环孢菌素A的诱变育种及其发酵工艺优化研究[J]. 中兽医医药杂志, 2021, 40(2): 19-22.
	ZHOU L, SHI Y P, NIU C, et al.. Study on mutation breeding and fermentation optimization of cyclosporin A[J]. J. Tradit. Chin. Vet. Med., 2021, 40(2): 19-22.
20	FALAH F, MORTAZAVI SALI, DANESH A, et al.. Production of cyclosporin A by Tolypocladium inflatum using dairy waste medium: optimization and investigation of the effect of ultrasound, high hydrostatic pressure, and pulsed electric field treatments on the morphology of fungus[J]. Biomass Convers. Biorefin., 2024, 14(22): 29101-29113.
21	刘雨, 王会会, 赵建辉, 等. 雪白白僵菌高产环孢菌素A发酵条件优化[J]. 发酵科技通讯, 2021, 50(4): 198-201.
	LIU Y, WANG H H, ZHAO J H, et al.. Optimization of fermentation conditions for high production of cyclosporin A from Beauvcria nivea [J]. Bull. Ferment. Sci. Technol., 2021, 50(4): 198-201.
22	张梦菲, 余炼, 李菲, 等. 响应面法优化暹罗芽孢杆菌产大环内酯的发酵培养条件[J]. 生物技术通报, 2024, 40(8): 299-308.
	ZHANG M F, YU L, LI F, et al.. Optimization of fermentation culture conditions for macrolactins yield of Bacillus siamensis using response surface methodology[J]. Biotechnol. Bull., 2024, 40(8): 299-308.
23	孔蒙蒙, 金静静, 卢鹏, 等. 高产纤维素酶工程菌株产酶条件优化[J]. 生物技术进展, 2024, 14(6): 1032-1041.
	KONG M M, JIN J J, LU P, et al.. Optimization of enzyme production conditions of high-yielding cellulase engineering strains[J]. Curr. Biotechnol., 2024, 14(6): 1032-1041.

编码	组分	水平
编码	组分	-1	1
A	玉米浆粉/%	3	6
B	麦芽糊精/%	8	14
C	葡萄糖/%	0.5	1.5
D	酵母浸粉/%	0.1	0.2
E	PEG200/%	0.1	0.5
F	发酵时间/%	7	10
G	硫酸铵/%	0.1	1.0
H	发酵温度/℃	24	26

编码	组分	水平
编码	组分	-1	1
A	玉米浆粉/%	3	6
B	麦芽糊精/%	8	14
C	葡萄糖/%	0.5	1.5
D	酵母浸粉/%	0.1	0.2
E	PEG200/%	0.1	0.5
F	发酵时间/%	7	10
G	硫酸铵/%	0.1	1.0
H	发酵温度/℃	24	26

因素	编码	水平
因素	编码	-1	0	1
玉米浆粉/%	X₁	4	6	8
硫酸铵/%	X₂	0.1	0.2	0.3
发酵时间/d	X₃	9	10	11
葡萄糖/%	X₄	0.4	0.6	0.8

因素	编码	水平
因素	编码	-1	0	1
玉米浆粉/%	X₁	4	6	8
硫酸铵/%	X₂	0.1	0.2	0.3
发酵时间/d	X₃	9	10	11
葡萄糖/%	X₄	0.4	0.6	0.8

来源	平方和	自由度	均方	F值	P值
模型	37.39	8	4.67	9.87	0.043
A-玉米浆粉	9.32	1	9.32	19.68	0.021 3
B-麦芽糊精	4.36	1	4.36	9.22	0.056
C-葡萄糖	6.39	1	6.39	13.49	0.034 9
D-酵母浸粉	1.91	1	1.91	4.03	0.138 4
E-PEG200	0.045 4	1	0.045 4	0.095 8	0.777 2
F-发酵时间	8.18	1	8.18	17.27	0.025 3
G-硫酸铵	6.13	1	6.13	12.94	0.036 8
H-发酵温度	1.06	1	1.06	2.24	0.231 4
残差	1.42	3	0.473 5
总和	38.81	11

基于响应面法优化环孢菌素A发酵工艺的研究

Optimization of Fermentation Culture Conditions for Cyclosporine A Using Response Surface Method

RichHTML

PDF

可视化

摘要/Abstract

引用本文

使用本文

图/表 11

参考文献 23

相关文章 5

编辑推荐

Metrics

本文评价

编号	A	B	C	D	E	F	G	H	CsA含量/(mg·mL^-1)
1	1	-1	1	-1	1	1	-1	1	5.42
2	1	-1	-1	-1	1	-1	1	-1	6.69
3	-1	-1	-1	-1	-1	-1	-1	-1	6.53
4	1	1	1	-1	-1	-1	1	1	5.63
5	1	-1	1	1	1	-1	-1	1	7.45
6	-1	1	1	-1	1	1	1	-1	6.91
7	1	-1	1	1	-1	1	1	-1	7.65
8	-1	1	-1	1	1	-1	1	1	6.19
9	-1	-1	-1	1	-1	1	1	1	7.10
10	1	1	-1	1	1	1	-1	-1	11.44
11	1	1	-1	-1	-1	1	-1	1	10.89
12	-1	1	1	1	-1	-1	-1	-1	7.02

编号	玉米浆粉/%	葡萄糖/%	硫酸铵/%	发酵时间/d	CsA含量/(mg·mL^-1)
1	3	1.2	0.3	7	8.48
2	4	1.0	0.25	8	10.66
3	5	0.8	0.2	9	10.90
4	6	0.6	0.20	10	11.53
5	7	0.4	0.15	11	8.62
6	8	0.2	0.10	12	6.69
7	9	0	0.05	13	6.51

实验编号	X₁	X₂	X₃	X₄	CsA含量/(mg·mL^-1)
1	1	2	-1	1	8.94
2	0	0	0	0	11.92
3	-1	1	-1	1	8.84
4	1	-1	2	1	10.60
5	0	2	0	0	10.57
6	-1	-1	1	1	10.31
7	0	-2	0	0	10.12
8	-2	0	0	0	7.12
9	0	0	0	0	11.93
10	-1	1	1	1	9.59
11	2	0	0	0	7.87
12	1	-1	-1	-1	9.65
13	0	0	-2	0	8.75
14	1	1	1	-1	10.14
15	0	0	0	-2	10.04
16	0	0	0	0	11.77
17	0	0	0	0	11.30
18	-1	-1	-1	-1	9.71
19	-1	1	-1	-1	9.57
20	-1	-1	1	-1	10.50
21	1	-1	1	-1	10.92
22	0	0	2	0	11.23
23	1	1	1	1	10.90
24	-1	-1	-1	1	9.86
25	1	-1	-1	1	9.78
26	0	0	0	0	11.55
27	0	0	0	2	10.15
28	1	1	-1	-1	8.30
29	0	0	0	0	11.91
30	-1	1	1	-1	10.31

来源	平方和	自由度	均方	F值	P值
模型	39.52	14	2.82	14.37	<0.000 1	**
X₁-玉米浆粉	0.17	1	0.17	0.87	0.366 5
X₂-硫酸铵	0.62	1	0.62	3.14	0.096 7
X₃-发酵时间	7.68	1	7.68	39.08	<0.000 1	**
X₄-葡萄糖	0.000 1	1	0.000 1	0.000 6	0.981 3
X₁X₂	0.02	1	0.02	0.12	0.734 8
X₁X₃	0.63	1	0.63	3.18	0.094 7
X₁X₄	0.45	1	0.45	2.29	0.150 6
X₂X₃	0.24	1	0.24	1.22	0.286 4
X₂X₄	0.002 4	1	0.002	0.01	0.913 0
X₃X₄	0.03	1	0.028	0.14	0.709 1
X₁²	27.11	1	27.11	138.04	<0.000 1	**
X₂²	2.19	1	2.19	11.16	0.004 5	**
X₃²	3.77	1	3.77	19.20	0.000 5	**
X₄²	3.26	1	3.26	16.61	0.001 0	**
残差	2.95	15	0.20
失拟项	2.62	10	0.26	3.96	0.070 9
纯误差	0.33	5	0.066
总和	42.47	29

组别	CsA含量/（mg·mL^-1）
初始组	7.95±0.72
预测组	11.87±0.18*
验证组	11.76±0.47*
